Capacitors in series and parallel

Capacitors in a parallel alignment

This is the easier of the two to calculate, the total capacitance is simply the sum of both of the capacitors.

cap seriesCapacitors in parallel

Capacitors in a series alignment

When calculating capacitance in series, it’s a little more complicated. But so long as you follow the formula, it should be okay. In addition to this, you can double check your results, because it should always be lower than the value smallest capacitor in the series.

para capCapacitors in series
